Dimensional and electrical reference · Copper · 600 V
- Conductor material
- Copper (Cu)
- Insulation material
- PVC + nylon
- Rated voltage
- 600 V
- Maximum conductor temperature
- 90°C
- Jacket / armour
- PVC
- Ampacity basis
- 2023 NEC Table 310.16; applicable correction and termination rules apply
Dimensional and electrical reference · Copper · 600 V| Configuration | Nominal area / conductormm² | Conductor sizeAWG / kcmil | Insulated conductors | Strands per conductor | Diameter over bare conductormm | Insulation wallmm | Diameter over insulationmm | Bond / ground conductorNo. × AWG | Outer jacket wallmm | Overall dimensions / diametermm | Copper weightkg/km | Approximate cable weightkg/km | Minimum bend radiusmm | DC conductor resistance at 25°CΩ/km | AC resistance at 75°CΩ/km | Inductive reactance at 60 HzΩ/km | Reference ampacity, 60°C columnA | Selection |
|---|
| 14/4 | 2.081 | 14 | 4 | Solid | 1.626 | 0.406 | 2.388 | 1 x 14 | 0.762 | 8.89 | 93.8 | 142.9 | 35.56 | 8.632 | 10.712 | 0.19 | 15 | |
|---|
| 14/2 | 2.081 | 14 | 2 | Solid | 1.626 | 0.406 | 2.388 | 1 x 14 | 0.635 | 9.449x4.47 | 55.1 | 89.3 | 17.78 | 8.632 | 10.712 | 0.19 | 15 | |
|---|
| 14/3 | 2.081 | 14 | 3 | Solid | 1.626 | 0.406 | 2.388 | 1 x 14 | 0.635 | 12.141x4.47 | 74.4 | 122 | 17.78 | 8.632 | 10.712 | 0.19 | 15 | |
|---|
| 12/4 | 3.309 | 12 | 4 | Solid | 2.057 | 0.406 | 2.819 | 1 x 12 | 0.762 | 10.058 | 148.8 | 205.4 | 40.64 | 5.453 | 6.768 | 0.177 | 20 | |
|---|
| 12/2 | 3.309 | 12 | 2 | Solid | 2.057 | 0.406 | 2.819 | 1 x 12 | 0.635 | 10.719x4.826 | 87.8 | 128 | 20.32 | 5.453 | 6.768 | 0.177 | 20 | |
|---|
| 12/3 | 3.309 | 12 | 3 | Solid | 2.057 | 0.406 | 2.819 | 1 x 12 | 0.635 | 13.31x4.826 | 117.6 | 171.1 | 20.32 | 5.453 | 6.768 | 0.177 | 20 | |
|---|
| 10/4 | 5.261 | 10 | 4 | Solid | 2.591 | 0.533 | 3.607 | 1 x 10 | 0.762 | 12.192 | 230.7 | 308 | 48.26 | 3.412 | 4.236 | 0.164 | 30 | |
|---|
| 10/2 | 5.261 | 10 | 2 | Solid | 2.591 | 0.533 | 3.607 | 1 x 10 | 0.635 | 12.827x5.537 | 136.9 | 189 | 22.86 | 3.412 | 4.236 | 0.164 | 30 | |
|---|
| 10/3 | 5.261 | 10 | 3 | Solid | 2.591 | 0.533 | 3.607 | 1 x 10 | 0.635 | 16.002x5.588 | 183 | 251.5 | 22.86 | 3.412 | 4.236 | 0.164 | 30 | |
|---|
| 8/3 | 8.366 | 8 | 3 | 7 | 3.607 | 0.787 | 5.131 | 1 x 10 | 0.762 | 14.859 | 275.3 | 386.9 | 58.42 | 2.142 | 2.657 | 0.171 | 40 | |
|---|
| 8/2 | 8.366 | 8 | 2 | 7 | 3.607 | 0.787 | 5.131 | 1 x 10 | 0.762 | 15.951x7.061 | 197.9 | 284.2 | 27.94 | 2.142 | 2.657 | 0.171 | 40 | |
|---|
| 6/3 | 13.302 | 6 | 3 | 7 | 4.521 | 0.787 | 6.045 | 1 x 10 | 0.762 | 17.069 | 410.7 | 543.2 | 68.58 | 1.348 | 1.673 | 0.167 | 55 | |
|---|
| 6/2 | 13.302 | 6 | 2 | 7 | 4.521 | 0.787 | 6.045 | 1 x 10 | 0.762 | 17.78x7.976 | 287.2 | 386.9 | 33.02 | 1.348 | 1.673 | 0.167 | 55 | |
|---|
| 4/3 | 21.151 | 4 | 3 | 7 | 5.715 | 1.067 | 7.747 | 1 x 8 | 0.762 | 21.438 | 656.3 | 857.2 | 86.36 | 0.846 | 1.05 | 0.157 | 70 | |
|---|
| 2/3 | 33.631 | 2 | 3 | 7 | 7.188 | 1.067 | 9.22 | 1 x 8 | 0.762 | 22.53 | 998.6 | 1235.2 | 88.9 | 0.531 | 0.659 | 0.148 | 95 | |
|---|
